84R / 38R Louvers

Linear 84R / 38R Cladding is known for its attractive and fluid lines. Panels can be easily removed and replaced by hand allowing easy and full access to services. Their effect is simple but pleasant. Linear Exterior Cladding can be fixed horizontally or vertically with multi space cladding System.

Panel: Round edge, 84mm / 38mm wide, 15 mm deep, length up to 3 mtr.

Material: Galvanized Steel 0.5mm, Aluminum 0.65mm / 0.71mm TCT

Carrier: Carrier Shall be 20mm wide at bottom & 42mm deep of 0.6mm Galvanized Steel stove enameled black to hold Panel in module of 16mm / 32mm / 42mm.

Paint Finish: 50-55 microns thick powder coating on exposed surface or 25 microns polyester coil coated over primer on visible surface with primer coat on rear side.
